Leasing Urtopia Fusion
Fiber
Hartmut Esslinger
Legendary Designer
For Apple & Sony
Designed by the legendary Hartmut Esslinger, the Fusion embodies his philosophy of blending form and emotion.
With safety, versatility, and user-friendliness all converge to elevate the riding experience, the Fusion sets the tone for a new era of e-bike innovation.
More Carbon.
Less Weight.
The carbon fiber contributes to the unique curved design and smooth finish, offering lightweight yet sturdy construction.
Resilient to impact and corrosion, the carbon frame ensures durability and long-lasting performance for all your riding needs.
- Super Lightweight e-SUV
- Racecar-grade carbon fiber
Be the first to uncover exciting Urtopia eBike deals and events!
Enjoy Easy
Entry Comfort
The deep step-through frame ensures easy access and a comfortable riding experience.
With an adjustable stem and SR Suntour suspension fork, Fusion offers an upright riding position and smooth handling.
- Low step-through
- Suspension fork (100 mm travel)
Effortless Terrain Mastery
With a robust 95Nm middle motor and wide range gears, the Fusion smoothly tackles hills and trails.
Enhanced by fat tires that provide excellent traction and stability, it’s ready for a ride navigating gravel paths and venturing off-road onto rugged trails.
- 95 Nm Torque
- Intuitive mid-drive motor
- Integrated Torque Sensor
Embrace Extended Adventures
Confidently embark on long-distance journeys with Fusion’s extensive range up to 240 km (Dual Battery) and dependable hydraulic disc brakes for superior all-weather control during extended rides.
- 240 Km All-day range
- Dual Battery option (900 Wh)
Charge up anytime,
anywhere
The removable battery is cleverly concealed within the downtube of the bike, blending seamlessly with the frame color design.
You can’t even tell its an ebike at first sight.
- Large Capacity (540 Wh)
- Seamlessly Integrated
The joy of cycling goes beyond.
Theft Protection
Receive alerts for unauthorized movement, easily locate where you parked, and track its movements with GPS tracking.
Navigation
Input your destination into the Urtopia App, and the smartbar will display clear navigation instructions accompanied by audio cues.
Fitness and Watch Support
Sync your rides with Apple Health and Strava integration to track, analyze, and share your cycling activities for fitness progress and community engagement.
Dashboard
The multi-screen data display ensures simplicity and visual clarity, while also catering to observation for various data indicators.
Music
Sync your phone with the speaker, transforming your ride into a melodic journey with your favorite tunes.
>Size Guide
>Specs
Size & Fit
✕A. Standover height
840 mmB. Adjustable seat range
60 mmC. Handlebar grips height
1020 mmD. Seat tube length
500 mmE. Wheelbase
1120 mmF. Overall length
1850 mmG. Wheel diameter
690 mmH. Top tube length (effective)
610 mmI. Head tube length
180 mmJ. Headset height
100 mmTechnical Specifications
✕Smart Functions
Smartbar features
Voice control, fingerprint unlock, LED dot-matrix display
Connectivity
Connect Service with 4G, Bluetooth & WiFi
IoT sensors
Accelerometer, gyroscope, torque
App
iOS & Android
Connect Service
1 year included*
Power
Motor
Carbon 1: 36V 250W(rated), 35 N.m
Carbon 1s: 36V 250W(rated), 45 N.m
Speed modes
Pedal, Eco, Comfort, Sport, Turbo
Top speed (assisted)
16 mph (25 km/h)
Range
40~100 km
Removable battery
9.8 Ah 352.8 Wh Samsung Li-ion, 2.5-hr quick charge
General
Weight
Carbon 1: 15 kg
Carbon 1s: 15.8 kg
Payload Capacity
Max. 110 kg
Size
One Size (see Size Guide)
Body material
Carbon fiber (frame, fork, handlebar, seatpost)
Brakes
Front and rear dual-piston hydraulic disc brakes
Gearing
Carbon 1: Gates Carbon Drive™ CDN™ belt(up to 30,000km)
Carbon 1s: Shimano 7-Speed Rear Drivetrain with ALIVIO Rear Derailleur
Integrated lights
StVZO headlight; Advanced Rear Early-indication System (ARES)
Wheels
700C (ISO 622 mm BSD), inner rim 19 mm
Tires
Kenda Kwest 700x35C (35 mm / 1.4”) (30~45 mm compatible)
What’s in the Box
Urtopia Carbon one
Front Wheel, Frame, Seatpost, saddle, Pedals
Removable battery
Battery, Charger, Battery key
Frame (accessory) bag
4mm Allen wrench, 15mm combination wrench, front-wheel quick-release device
*This service will be automatically activated once the bike is activated and bound to your account. We provide free access in the first year, with the following terms to be renewed by subscription to this service. A code will be sent to your email which can be used to renew the service in our App.
Urtopia Caring
✕Customer-Centric
2-Year Warranty
All Urtopia bikes are covered under our 2-year Limited Warranty for the owner against all manufacturing defects.
Easy to Claim Process
Contact care@newurtopia.com for warranty claims
14-Day Free Return
Free return of unused products within 14 days of delivery.
Favorable Shipping Fees
Free shipping for defective-on-arrivals, and lower fees for returns/replacements.
Authorised Service Providers
We have over 50 authorized repair shops across major cities in Germany to provide reliable after-sales service for our e-bikes. Our repair partners are experts in their field and have been carefully selected and trained to provide you with quality products and services. Simply visit one of our authorized repair shops for repairs or maintenance. We’re committed to ensuring that you have a positive experience with our e-bikes.
Urtopia Care
Tutorials & FAQs
Our comprehensive online resources include detailed instruction, troubleshooting videos with step-by-step teaching, and FAQ to address your concerns.
Help with my bike
Something not right with your bike? We’ll guide you step by step to resolve the issue.
Talk to Us
Our expert service representatives can effectively identify and solve uncommon issues to ensure your satisfaction.
Video Calls
Connect with our friendly technical team in real-time via Zoom for patient, expert guidance on any issue.
